Frame depths of 115 mm (4 1/2’’)

44.5mm  (1 3/4’’) 24 Gauge Insulated steel door slab

A low maintenance option for terrace door application with rain screen design (Pressure Equalized)

Extruded screw spline joinery

A variety of fixed and operable inserts are available in different sizes

Interior or exterior glazed (Depending on swing orientation) Replaceable, high quality compression seals

Available with multipoint lock system

Ideal for punched opening applications

13mm thermal break permits split interior/exterior finishes

Strap anchor option makes installation easy

Accepts 25.4mm (1”) O/A Glazing for door insert & 15.8mm (5/8) for transom

Tested to NAFS-CW, AAMMA and CSA requirements

Finish in Duracron, Acrynar, Duranar (XL) and Anodized
